Davis Instruments: Vantage Pro2 Plus Stations with WeatherLink Console

The Vantage Pro2 Plus 6262M is rugged, accurate, and trusted by agriculture, environmental research, and municipal early warning networks. Includes all the features of the VantagePro2, plus UV and Solar Radiation sensors. The Vantage Pro2 Plus provides, real-time data updates every 2.5 seconds. It features an industry-leading transmission range of 1000'/300m from the sensor suite to the included Wi-Fi WeatherLink Console

SKU-6262M Includes:

 UV and Solar radiation sensors
 Outside Temp. and humidity sensors housed in a passive radiation shield
 Wind speed and Wind direction sensors
 Rainfall sensor
 Sensor Transmitter
 WIFI WeatherLink Console

* Mounting pole kit and tripod sold separately

* UV and Solar radiation sensors are not included with 6252M

Operating Temperature	-40 to +65C
Non-operating Temperature	-40 to +70C
Current Draw (ISS SIM only)	0.14 mA (average), 30 mA (peak) at 4 to 6 VDC
Solar Power Panel	0.5 Watts (ISS SIM) + 0.75 Watts (Fan-Aspirated)
Battery (ISS SIM / Fan-Aspirated)	CR‑123 3‑Volt Lithium cell / 2 x 1.2 Volt NiMH C‑cells
Battery Life (3‑Volt Lithium cell)	8 months without sunlight; greater than 2 years with solar charging
Battery Life (NiMH C‑cells, Fan-Aspirated)	Up to 2 years
Fan Aspiration Rate (Fan-Aspirated only)
Intake Flow Rate, full sun	190 ft/min (0.9 m/s)
Intake Flow Rate, battery only	80 ft/min (0.4 m/s)
Sensor Chamber Flow Rate, full sun	500 ft/min (2.5 m/s)
Sensor Chamber Flow Rate, battery only	180 ft/min (0.9 m/s)
Connectors, Sensor	Modular RJ‑11
Cable Type	4‑conductor, 26 AWG
Cable Length, Anemometer	40 ft (12 m) included; 240 ft (73 m) maximum recommended
Wind Speed Sensor	Solid state magnetic sensor
Wind Direction Sensor	Wind vane with potentiometer
Rain Collector Type	Tipping spoon, 0.01" per tip for US versions, 0.2 mm for metric versions, 33.2 in2 (214 cm2) collection area
Temperature Sensor Type	PN Junction Silicon Diode
Relative Humidity Sensor Type	Film capacitor element
Housing Material	UV-resistant ABS, polypropylene
